DESCRIPTION

This panel is mainly used for application in auditoriums, conference rooms, multipurpose rooms, places where acoustic treatment with a continuous coating surface is required. It is an absorbent panel that provides a relevant balance in the mid-range of the sound spectrum and also combines features of a unidirectional diffuser.

There are six types of perforations that give this product several aesthetic and acoustic variants.

This product uses three absorbent materials inside it which have different densities that allow different degrees of permeability, thus making it more efficient at absorbing sound.

In large areas, its application may be continuous or modular, thus combining features of other products from this catalogue.

Although this panel is manufactured in standard sizes, other measurements can be considered depending on each project.

This product is very popular because the use of wood in rooms makes them look comfortable.

FEATURES

Recycled
Made with 80% of recycled materials
NRC [>250Hz; <10KHz]
(ADD 0.56/m2), (ADDHC 0.71/m2), (ADDG 0.60/m2), (ADDS 0.78/m2), (ADDSL 0.79/m2), (ADDC 0.81/m2)
Fire-resistance
Euroclass B-s2,d0 (similar to old M1)
Recyclable
100% recyclable
Installation
Acessories included
Sizes
Other sizes are available on demand

TECHNICAL DRAWINGS

PRODUCT DIMENSIONS

Model Height Width Depth Weight
ADD060 60 cm (23,6") 60 cm (23,6") 8 cm (3,1") 6.3 kg (13 lbs 14 oz)
ADD120 120 cm (47,2") 60 cm (23,6") 8 cm (3,1") 12.6 kg (27 lbs 12 oz)
ADD180 180 cm (70,9") 60 cm (23,6") 8 cm (3,1") 18.9 kg (41 lbs 11 oz)

ABSORPTION COEFFICIENT
